Lenox Cast Master™ – & CAST MASTER XL/ XLE-SERIE
Superior performance in aluminum cutting applications
LONG BLADE LIFE IN CASTING APPLICATIONS
The special carbide is designed for slow wear when cutting aluminum
CUTS FREELY AT INCREASED CUTTING SPEEDS
Multi chip tooth design reduces cutting forces and limits vibrations
Precision grinding prevents accumulation of material on the tooth edge
Extra information
Application
Aluminum/Non-Ferrous, Wood, Composites
Height
12,7 mm, 19 mm, 27 mm, 34 mm, 41 mm, 54 mm, 67 mm, 80 mm
Width
0.64 mm, 0.90 mm, 1.07 mm, 1.27 mm, 1.60 mm
Teeth per inch
0.6/0.8, 0.9/1.1, 1.4/2.0, 2/3, 3/4, 3
Specifications & Application
| Width & thickness | TPI (teeth per inch) | |||||
|---|---|---|---|---|---|---|
| In millimetres | 0,6/0,8 | 0,9/1,1 | 1,4/2,0 | 2/3 | 3 | 3/4 |
| 12,7 x 0,64 | ✔ | |||||
| 19 x 0,90 | ✔ | ✔ | ||||
| 27 x 0,90 | ✔ | ✔ Δ | ||||
| 34 x 1,07 | ✔✔ | ✔ | ✔ | ✔ | ||
| 41 x 1,27 | ✔✔ * | ✔ | ||||
| 54 x 1,60 | ✔✔ | |||||
| 67 x 1,60 | ✔✔ | |||||
| 80 x 1,60 | ✔✔ | ✔✔ | ||||
✔✔ = Cast Master XL design
